UC C500 MJ TF S V2
Keystone Jack,Cat.6A,RJ45, FTP, 180° Tool Free, Shielded
- Category 6 A hardware compliant performance.
- Zinc Alloy housing provides 100% EMC and Alien Crosstalk protection.
- Tool-free termination.
- High Density Design provides optimize usage of rack space.
|
Specification |
|
|---|---|
| Item | Description |
| RJ45 Housing | Zinc Alloy with nickel plated |
| Contacts and IDC | Phosphor bronze |
| Contact Surface Finish | 50u" gold plated over contact area |
| IDC Surface Finish | Tin plated |
| IDC Housing | PC, UL94V0 |
| PCB | FR4 94V0 |
|
Performance |
|
|---|---|
| Item | Description |
| Wiring | TIA 568 A/B |
| Insertion Force | <=30N |
| Plug Insertion Life | 800 times insertion (RJ45, RJ11/RJ12) |
| Re-Termination | 10 Cycles |
| Wire Size Capability | 22 ~ 26 AWG solid wire |
| Ordering Information | ||||
|---|---|---|---|---|
| SAP IC | UC P/N | UC Material Code | Product Description | P.U |
| TBA | MJTF1000 | UC C500 MJ TF S V2 | Keystone Jack,Cat.6a,RJ45,FTP, 180° Tool Free, Shielded, HD | 1pc/bag |
