UCFIBRE™® Optical Adaptors

Overview

Draka offers an extensive range of optical adaptors for use in FTTx, telecommunications, data communications.
and CATV applications. All adaptors are fully qualified to Telcordia GR326 and IEC 61300 and all materials used are
RoHS compliant.

Adaptors can be supplied in a variety of colours and for a variety of different connector types such as FC, SC, ST,LC, E2000 etc. Further connector types are also available on re quest.

Features

  • Qualified to Telcordia GR326 and IEC 61300 standards and RoHS compliant materials.
  • Available for many different connector types such as FC, SC, ST, E2000, MTRJ, LC and others on request.
  • All adaptors are supplied with ceramic inserts.
  • Supplied in a range of different colours to match connector type .(e.g. blue for PC, green for APC, beige for multimode).
  • Both simplex and duplex adaptors are available.

Application

  • FTTx
  • Telecommunications
  • Data communication
  • CATV
  • Test and measurement







Technical data
Item No. Singlemode (1310/1550nm) Multimode (850nm)
Insertion Loss (dB) Typical ≤ 0.1dB;

Maximum ≤ 0.2 dB

 Typical ≤ 0.1dB;

Maximum ≤ 0.2 dB
Operating temperature -20°C to + 70°C
Ordering Information
UC P/N Product Description P.U
D540505 Draka UCCONNECT Optic Fibre Connector Simplex Single Mode FC-FC UPC 1 pc
D550505 Draka UCCONNECT Optic Fibre Connector Simplex Multi Mode FC-FC UPC 1 pc
D520606 Draka UCCONNECT Optic Fibre Connector Simplex Single Mode SC-SC UPC 1 pc
D530606 Draka UCCONNECT Optic Fibre Connector Simplex OM1 & OM2 Multi Mode SC-SC UPC 1 pc
D520707 Draka UCCONNECT Optic Fibre Connector Duplex Single Mode SC-SC UPC 1 pc
D530707 Draka UCCONNECT Optic Fibre Connector Duplex OM1 & OM2 Multi Mode SC-SC UPC 1 pc
* For more information, please download technical datasheet.

UCFIBRE™® Optical Pigtails

Overview

High performance optical pigtails ensuring network performs to the highest level. Draka offers an
extensive range of optical pigtails for use in FTTx, telecommunications, data communications and
CATV applications. All pigtails are fully qualified to Telcordia GR326 and IEC 61300 and all materials
used are RoHS compliant. can be supplied in a variety of length s and with a variety of different
connector types.

Features

  • Full traceability and test certification supplied with each assembly.
  • Ultra polish (UPC) supplied as standard and Angle polish (APC) also available.
  • Qualified to Telcordia GR326 and IEC 61300 standards and RoHS compliant materials properties.
  • Can be supplied with many different connector types such as FC, SC, ST, E2000, LC, DIN and others
    on request.
  • Available in single-mode and multimode (50/125 and 62.5/125).
  • Many fibre types available including single-mode, multimode, low loss & bend insensitive fibres.
  • Standard length supplied is 1m or 2m.
  • Standard cable diameter is 900 micron with easy strip buffering.
  • Ruggedized pigtails can also be supplied in 1.6mm, 2mm and 3mm.

Application

  • FTTx
  • Telecommunications
  • Data communication
  • CATV
  • Test and measurement




Technical data
Item No. Singlemode (1310/1550nm) Multimode (850nm)
Maximum Insertion Loss (dB)  Max. ≤ 0.25 dB
Return Loss (dB) ≥ 55 dB(UPC), ≥ 65 (APC) ≥ 30dB
Durability ≤ 0.2dB typical change per 500 mating
Operating temperature -20°C to +70°C
Ordering Information
Pigtail part numbers are made up using the table below.The part number always starts with the letters PT to denote tha t it is a pigtail. The first 2 digit code denotes the micron, followed by the next 2 letters which represents the connector type. The dash is next, followed by a number to denote the length of the pigtail.Note: Pigtails must be ordered in 1 metre increments.Example of a pigtail part number: – PT09SC-1. The above example describes a pigtail 1 metre in length, with S C connector on one end. It is an OS1/2 (9um) pigtail.

PIGTAIL MICRON CONNECTOR LENGTH
PT XX XX – XX
009 – 9um OS1 / OS2
050 – 50um OM2
062 – 62.5um OM1
033 – 50um OM3
040 – 50um OM4
 SC
ST
LC
FC		 EXAMPLES:

1 = 1m
2 = 2m
15 = 15m
99 = 99m

UCFIBRE™® Optical Patchcords

Overview

High performance optical patchcords ensuring network performs to the highest level. Draka offers
an extensive range of optical patchcords for use in FTTx, telecommunications, data communications
and CATV applications. All patchcords are fully qualified to Telcordia GR326 and IEC 61300 and all
materials used are RoHS compliant. Can be supplied in a variety of lengths and with a variety of
different connector types. Different fibre types and cable diameters are also available on request.
Hybrid patchcords with different connector types on each end are also available.

Features

  • Full traceability and test certification supplied with each assembly.
  • Ultra polish (UPC) supplied as standard and Angle polish (APC) also available.
  • Qualified to Telcordia GR326 and IEC 61300 standards and RoHS co mpliant materials.properties.
  • Can be supplied with many different connector types such as FC, SC, ST, E2000, LC, DIN and others
    on request.
  • Available in singlemode and multimode (50/125 and 62.5/125).
  • Many fibre types available including singlemode, multimode, low loss & bend insensitive fibres.
  • Lengths available from 1 metre to 99 metres.
  • Cable diameters available in 1.6mm, 2mm and 3mm.
  • Standard thickness, LC-LC (2m), LC-others (3m).
  • All connectors are supplied with ceramic ferrules.

Application

  • FTTx
  • Telecommunications
  • Data communication
  • CATV
  • Test and measurement



Technical data
Item No. Singlemode (1310/1550nm) Multimode (850nm)
Insertion Loss (dB) Maximum ≤ 0.25dB
Return Loss (dB) ≥ 50dB (UPC), ≥ 65dB (APC) ≥ 30 dB
Durability ≤ 0.2dB typical charge per 500 matings
Operating temperature -20°C to + 70°C -20°C to + 70°C
Ordering Information
Patchcord part numbers are made up using the table below.The part number always starts with the letters PC to denote that it is a patchcord. This is followed by a letter which signifies the type of termination and then another letter to denote the sheath of the patchcord. The first 2 numbers represents the micron, and the second set of numbers represents the connector The dash is next, followed by a number to denote the length of the patchcord. Note: Patchcords must be ordered in 1 metre increments. Example of a patchcord part number:PCDL06209-1. The above example describes a patchcord 1 metre in length, with LC/FC connectors on both ends. It is an OM1 (62.5um) duplex patchcord with a LSZH sheath.

PATCHCORD TERMINATION (DUPLEX) SHEATH MICRON CONNECTOR LENGTH
PC D L XX XX – XX
LSZH
009 – 9um OS1/OS2
062 – 62.5um OM1
050 – 50um OM2
033 – 50um OM3
043 – 50um OM4
 01-SC-SC
02-SC-FC
03-SC-ST
04-FC-FC
05-FC-ST
06-ST-ST
07-LC-LC
08-LC-SC
09-LC-FC
10-LC-ST		 EXAMPLES:

1 = 1m

2 = 2m

15 = 15m

99 = 99m


Note: Patchcords should
be ordered in 1m
(in one metres)
